2009 KTM 990 Super Duke R

1920x1200 - Wallpaper, Click on the Image then Right Click and Save it.

Overview

When riding fun becomes an addiction. All-consuming passion.

You can barely find words to express the riding fun and the feeling that the KTM 990 Super Duke gives you when it’s in motion. Just as KTM re-invented the Streetfighter, you try to invent new words for what happens beneath you curve after curve. The KTM 990 Super Duke sweeps through curves – ultra-precise, radical and agile. The landscape flies past fast, faster, much too fast. You feel the road, the centrifugal force and want more.

1920x1200 - Wallpaper, Click on the Image then Right Click and Save it.

1920x1200 - Wallpaper, Click on the Image then Right Click and Save it.

1920x1200 - Wallpaper, Click on the Image then Right Click and Save it.

1920x1200 - Wallpaper, Click on the Image then Right Click and Save it.

1920x1200 - Wallpaper, Click on the Image then Right Click and Save it.

1920x1200 - Wallpaper, Click on the Image then Right Click and Save it.

2009 KTM 990 Super Duke R - Specifications

Engine type Twin cylinder, 4-stroke, V 75°

Displacement 999 cc

Bore x stroke 101 x 62.4 mm (3.98 x 2.46")

Performance (homologated) 97 kW @ 10000 rpm

Max. torque 102 Nm @ 8000 rpm

Compression ratio 11.5:1

Starter/Battery E-Starter/12 V 11.2 Ah

Transmission 6 gears, dog-clutch engagement

Fuel Mixture Generation Keihin electronic fuel injection

Control 4 V/DOHC

Lubrication Pressure lubrication with 2 Eaton pumps

Engine lubrication Motorex, fully synthetic, SAE 10W-50

Primary drive 67:35

Final drive 16:38

Cooling Liquid cooled

Clutch Wet multi-disc clutch, operated hydraulically

Motor Management Keihin EMS

Frame Chromium-Molybdenum trellis frame, powder coated

Subframe Aluminium 7020

Handlebar Aluminium, Ø 28/22 mm (1.10/0.87"), tapered

Front suspension WP USD Ø 48 mm (1.89")

Rear suspension WP mono shock

Suspension travel front/rear 135/150 mm (5.31/5.91")

Front brake 2 x Brembo Vierkolben-Radialfestsattel, Bremsscheiben Ø 320 mm

Rear brake Brembo single-piston, floating caliper, brake disc Ø 240 mm (9.45")

Rims, front/rear Cast aluminium wheels 3.5 x 17"; 5.5 x 17"

Tires, front/rear 120/70 ZR 17"; 180/55 ZR 17"

Chain X-Ring 5/8 x 5/16"

Battery 12 V/11.2 Ah

Main silencer Stainless steel silencer with regulated catalytic converter

Steering head angle 67.3°

Trail 93.9 mm

Wheel base 1450 ± 15 mm (57.09 ± 0.59")

Ground clearance (unloaded) 140 mm (5.51")

Seat height 865 mm (34.06")

Tank capacity approx. 18.5 liters/2.5 liters reserve (4.89/0.66 gal)

Weight (no fuel) approx. 186 kg (410.05 lbs).
